Description
8CH WEATHERPROOF DVR WPHD8A
- NEMA rated outdoor enclosure with fan and thermostat
- Full featured H.264 compression DVR for extended record time and faster network transmission
- 6-outlet power strip for 24V devices like heated housings or PTZ’s
- The mounting brackets allow for flush or pole mounting
- 2.4 Ghz wireless bridge for transmitting distances up to 1.5 miles over wireless LAN
OVERVIEW
8 Channel, self-contained HD weatherproof DVR packaged inside AL191912N3 for remote site recording. Package includes PWR98A power supply, LED monitor, 8ch HD DVR from Optiview with 4TB storage, and universal mounting brackets for wall or pole mounting.
SPECIFICATIONS
| Enclosure Material | 5052 Aluminum |
| Enclosure Color | Silver / Metalic |
| Power Supply | 9ch 12VDC, 8amp |
| Voltage | 120V AC (Power Strip) |
| Mounting Plate Material | Aluminum |
| Mounting Plate Dimensions | 17″ × 16″ (431.8mm × 406.4mm) |
| Weight (Enclosure Only) | 41 lbs |
| Outside Dimensions | 19″ × 19″ × 12″ (482.6mm × 482.6mm × 304.8mm) |
| Cable Feed | 1.2″ Cable Conduit Connector |
| Ratings | NEMA 3 |
RESOURCES
PDF Spec Sheet –Download
