Description

ASRock H670M-ITX/ax Desktop Motherboard – Intel H670 Chipset – Socket LGA-1700 – Intel Optane Memory Ready – Mini ITX – Pentium Gold, Celeron, Core i5, Core i7, Core i9, Core i3 Processor Supported – 64 GB DDR4 SDRAM Maximum RAM – DIMM, UDIMM – 2 x Memory Slots – IEEE 802.11 a/b/g/n/ac/ax – HDMI – DisplayPort – 4 x SATA Interfaces

• Supports 12th Gen Intel^® Core™ Processors (LGA1700)
• 8 Phase Dr.MOS Power Design
• Supports DDR4 5000MHz (OC)
• 1 PCIe 5.0 x16
• Graphics Output Options: HDMI, DisplayPort
• Realtek ALC897 7.1 CH HD Audio Codec, Nahimic Audio
• 4 SATA3
  1 Hyper M.2 (PCIe Gen4 x4)
  1 Hyper M.2 (PCIe Gen4 x4 & SATA3)
• 1 Rear USB 3.2 Gen2x2 Front Type-C
  2 Rear USB 3.2 Gen2
  3 USB 3.2 Gen1 (2 Front, 1 Front Type-C)
• Dragon 2.5G LAN, Intel^® Gigabit LAN
• 802.11ax (WiFi 6E) + Bluetooth

Optimized VRM DesignDr.MOS is the integrated power stage solution which is optimized for synchronous buck-set down voltage applications! Compared to traditional discrete MOSFETs, it intelligently delivers higher current for each phase, thus providing improved thermal result and superior performance.
