Description

Digi IX30 — FirstNet Capable LTE-Advanced Cat 7

• Cellular connectivity:
  • FirstNet Capable™ LTE-Advanced Cat 7
    • LTE-Advanced Cat 7 — FDD: B2, B4, B5, B7, B12, B13, B14 FirstNet®, B25, B26, B66, B71; TDD: B41, B42, B43, B48
    • WCDMA: B2, B4, B5
    • GNSS: GPS, GLONASS, BeiDou, Galileo, QZSS
  • Connectors: (3) 50 Ω SMA (2x cellular, 1x GNSS); center pin: female
  • SIM slots: (2) Mini-SIM (2FF)
  • SIM security: Secured in cellular module
  • GNSS: Protocol NMEA 0183 V3.0; Acquisition Time Hot Start 1 s; Warm Start 29 s; Cold Start 32 s; Accuracy Horizontal: < 2 m (50%), < 5 m (90%); Altitude: < 4 m (50%), < 8 m (90%); Velocity: < 0.2 m/s

• Software and management:
  • Remote management: Digi Remote Manager®, SNMP v1/v2c/v3 (user installed/managed), SMS
  • Local management: Web UI (HTTP/HTTPS); CLI (Telnet, SSH, Serial)
  • Management / troubleshooting tools: FTP, SFTP, SCP; protocol analyzer with PCAP for Wireshark; event logging with Syslog and SMTP; NTP/SNTP

• Ethernet:
  • ​Ports: (2) RJ-45; 10/100 Mbps (auto-sensing)

• Serial:
  • (1) DB-9 DTE
  • RS-232/422/285
  • Signal support: TXD, RXD, CTS, DTR, DCD, DSR, RI
  • Flow control: software (XON/OFF), hardware supported

• I/O:
  • Connector: 12-pin screw down terminal block
  • Digital: 0-30 VDC, 200 mA max.; (4) I/O, software-selectable; pulse counter input
  • Analog: (4) analog I/O; 4-20 mA or 0-10 V, software-selectable; 12-bit resolution

• USB:
  • Ports: (1) USB 2.0 Type A; 5 V 500 mA max

• Physical:
  • ​Dimensions (L x W x H): 12.8 cm x 10 cm x 5.2 cm (5.04 in x 3.94 in x 2.05 in)
  • Weight: 0.5 kg (1.1 lb)
  • Status LEDs: Signal Strength (5), LTE, Power
  • Enclosure/Rating: Aluminum / IP30
  • Mounting: DIN rail mount

• Power requirements:
  • Power input: 9 – 30 VDC, 18 W min power source required
  • Power connector: Screw down removable terminal block
  • Power consumption: 1.5 W (light traffic flow), 3.5 W (peak data transmission); 1 W (low power mode, idle traffic, no serial/no Ethernet WAN)

• Environmental:
  • Hazardous (Class 1 Div 2): Yes
  • Operating temperature: -34° C to 74° C (-29° F to 165° F); reduced cellular performance may occur above 60° C (140° F)
  • Storage temperature: -40° C to 85° C (-40° F to 185° F)
  • Ethernet isolation: 1.5 kV RMS
  • Serial port protection (ESD): 15 kV
  • Relative humidity: 5% to 95% (non-condensing)

• Approvals:
  • ​Cellular (IX30-00P7): PTCRB, Verizon, T-Mobile, AT&T, FirstNet Capable™; visit www.digi.com/resources/certifications for latest cellular certifications
  • Safety: Hazardous locations: ANSI/ISA-12.12.01-2015, CAN/CSA C22.2 NO.213-15; Ordinary locations: UL 62368-1, 2nd Edition, 2014-10-14; UL 62368: 2014, 2nd Edition; ATEX standards: Protection method II 3 G Ex nA IIC T4 Gc; EN 60079-0:2012+A11:2013, EN 60079-15:2010, DEMKO 15 ATEX 1574X Rev. 1
  • IECEX standards: US/UL/ExTR17.0077/00
  • Emissions / Immunity: CE, RED, FCC Part 15 Subpart B, ICES-003, AS/NZS CISPR 322
  • Environmental: RoHS3

• Product warranty: 3-year*

• Available accessories: Accessories not included;view available accessories
  • IX30 Accessory Kit — PSU, antennas, Cat 6 Ethernet cable, GPS antenna: 76002113 (recommended)
  • Power supply (required, choose industrial extended temperature or commercial)
    • Power supply — 18 VDC, 1 A, wall mount level VI, industrial temperature, changeable plug tips, 2-pin combicon screw terminal plug: 76002104
    • Power supply — 18 VDC, 1 A, wall mount level VI, commercial temperature, changeable plug tips, 2-pin combicon screw terminal plug: 76002117
  • Antenna — 5G/LTE 600 MHz – 6 GHz, swivel, black: 76002114 (recommended / optional)
  • Antenna base — SMA, 1 m, RG174: 76000954 (recommended / optional)
  • Cable — UTP, Cat 6, 2 m (6 ft), black, flat patch cable: 76002106 (recommended / optional)

What’s in the box:

• Digi IX30 — LTE-A Cat 7 North America, FirstNet Capable, dual Ethernet, RS-232/422/485, GNSS

*Standard 3-year warranty upgradeable to 5 years with purchase of a Digi Remote Manager Premier 5-year subscription applicable to the product purchased only at the time of product purchase and with product registration at that time in Digi Remote Manager.
